CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
156
6.2.3 Q
O
S (Q
UALITY OF
S
ERVICE
) C
ONFIGURATION
P
AGE
The QoS Configuration page is activated from the Main Menu page.
The QoS Configuration page contains the following options/fields:
Menu Options/Fields Entry Description
QoS Mode M Select;
Rule-Max/Pri Mode
Rule-Min/Max Mode
DiffServ Mode
QoS Rules Configuration Q Select to define QoS rules for Max/Pri Mode or
Min/Max Mode
DiffServ Rules Configuration D Select to define QoS rules for DiffServ Mode
Save Parameters S This option allows a user to save the current
configuration of the CDM-IP to permanent storage.
This configuration will be restored on each successive
power cycle of the CDM-IP.
Exit X This option allows a user to exit the current menu and
return to its parent menu.
