CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
191
Menu Options/Fields Entry Description
Queue01…08 Read
Only
Statistics are displayed in a table format showing:
Pre-Header Comp Bytes
Post-Header Comp Bytes
Header Comp % Savings
Pre-Payload Comp Bytes
Post-Payload Comp Bytes
Payload Compression Ratio
Global Read
Only
All traffic that does not fall within a defined QoS Rule
will be indicated in the ‘Global’ (Default Rule Queue).
CLEAR C Allows a reset of the Statistics of a specific Queue.
ClrAll A Resets all Compression Statistics.
Base [1] B Allows the user to view up to 8 different Queues per
screen. To allow editing on any of the 32 entries that
can be defined, the user can select a base address to
control which 8 QoS Queues are displayed. For
example, if the user wants to view QoS Queues 16-24,
then a Base value of 16 should be defined.
Save Parameters S This option allows a user to save the current
configuration of the CDM-IP to permanent storage.
This configuration will be restored on each successive
power cycle of the CDM-IP.
Exit X This option allows a user to exit the current menu and
return to its parent menu.
