CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
177
6.2.7.2 R
ECEIVE
M
ODEM
C
ONFIGURATION
P
AGE
The Receive Modem Configuration page is activated from the Modem Parameters page.
The Receive Modem Configuration Page contains the following options/fields:
Note: Turbo FEC selections only diplayed if Turbo card is installed
Menu Options/Fields Entry Description
Receiver Frequency Q Valid ranges are from 950 to 1750 MHz.
Receive Data Rate D Valid ranges are from 2.4 to 5000 kbps.
Decoder Type T 1 - NONE
2 - VIT
3 - TURBO_3/4_Q
4 - TURBO_B21/44
5 - TURBO_B5/16
6 - TURBO_3/4_OQ
Decoder Rate R 1 - 1/2
2 - 3/4
3 - 7/8
4 - 21/44
5 - 5/16
