CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
254
OID Description
cdmip300LModemTxTrafficFaults Returns the current fault and status codes for the Tx
Traffic. The value will be an integer between 0 and 31
where the bit that is set indicates the fault that has
occurred:
bit 0 Not used, always 0
bit 1 No clock from terrestrial
interface
bit 2 Tx FIFO slip
bit 3 AIS Detected on incoming data
bit 4 AUPC upper limit reached
cdmip300LModemRxTrafficFaults Returns the current fault and status codes for the Rx
Traffic. The value will be an integer between 0 and
255 where the bit that is set indicates the fault that
has occurred:
bit 0 Not used, always 0
bit 1 Demod Unlock
bit 2 AGC alarm
bit 3 Frame Sync lost
bit 4 Buffer underflow
bit 5 Buffer overflow
bit 6 AIS detected on incoming data
bit 7 E
b
/N
o
Threshold exceeded
