CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
184
Menu Options/Fields Entry Description
Dropped - No Route Total Dropped Packets due to no Route for the
destination in the CDM-IP Route Table. These are
packets that are directed to the CDM-IP’s MAC
address and the CDM-IP will reply to the sender with a
ICMP ‘Destination net unreachable’ message.
Dropped - Filtered Multicast
Sat To Ethernet Total Dropped Multicast Packets received from the
satellite due to no SAT
→LAN Route or the ‘Downlink
all available multicast’ feature not being enabled.
Dropped - QoS Filter Rule Total Dropped Packets due to a defined QoS filter rule.
Dropped - Filtered Indicates certain types of traffic that should not leak to
Satellite. For example, broadcasts destined for Satellite
LAN.
Dropped - Multicast Disable
Group Multicast packet was dropped because, although route
existed, IGMP is being used, and there is no client
requesting forwarding of this traffic or due to a IGMP
“leave group” message.
Dropped - No ARP Entry Total Dropped Packets due to no ARP entry in CDM-IP
ARP Table. For example, if a CDM-IP receives packets
from the satellite for a host that is not in the ARP table,
the CDM-IP will send an ARP request. If there is no
response, the packets will be dropped.
Dropped - Bad Buffer
Length IP length (as specified in packet header) was greater
than payload received in the Ethernet packet. This
would indicate the packet was truncated before
arriving.
Dropped - Bad IP Version Total Dropped IP Version 6 Packets (CDM-IP only
supports IP Version 4).
Dropped – easyConnect Multicast packets deopped in easyConnect when
Reset Packet Counters
(Clears WAN, Ether, IP
stats) R Executing this menu option resets all WAN, Ethernet
and IP Routing statistics gathered to zero.
Save Parameters S This option allows a user to save the current
configuration of the CDM-IP to permanent storage.
This configuration will be restored on each successive
power cycle of the CDM-IP.
Exit X This option allows a user to exit the current menu and
return to its parent menu.
