CDM-IP 300L IP-Centric Satellite Modem Rev. 1
CD/CDMIP300L.IOM
37
2.2 I
NSTALLATION
The modem arrives fully assembled from the factory. After unpacking the modem, install
the modem as follows:
2.2.1 IDU I
NSTALLATION
(O
PTIONAL
)
Refer to Table 10. Use Mounting Kit KT/6228-1.
Table 10. Optional: Mounting Kit , KT/6228-1 (IDU to Equipment Rack)
QTY Part Number Description
2 FP/6138-1 Bracket, Rear Support
4 HW/10-32x1/2RK Bolt, #10 Rack
2 HW/10-32X1/4 SHC Screw, Socket 10-32 x 1/4inch
Tools Required:
Screw Driver Phillips
SAE Allen Wrench 5/32-inch
Install the IDU rear support brackets as follows:
1. Install provided rear support bracket onto the mounting rail of the rack. Fasten with
provided bracket bolts.
2. Fasten the provided #10 socket head screws to the rear-side mounting holes on either
side of the chassis modem. Mount the modem into the equipment rack ensuring that the
socket heads engage into the slots of the rear support brackets.
Note: It may be necessary to adjust the location of the rear mounting rails of the rack.
