Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual

Page 77

background image

Drive Installation 2-47

7000 “C” Frame - Marine

7000L-UM302B-EN-P – June 2013

Motor Terminals

Voltage Sensing

Figure 2.56 – Motor Cable termination point


Load Cable Removable
Conduit Cover

Figure 2.57 – Motor Cable termination point (Removable gland plate)
