Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 315
Component Definition and Maintenance 4-139
7000 ―C‖ Frame - Marine
7000L-UM302B-EN-P – June 2013
-
From the File menu, click Open….At the Open dialog box,
locate the HyperTerminal connection you just created in step-2,
(eg. Parameters) and then click Open.
-
From the Transfer menu, select Capture Text… as shown below.
-
The Capture Text dialog box will appear. Click on Browse
button and search the file Example.txt that you created in Step-1
above.
-
Now click Start button.
