Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 76
2-46
Drive Installation
7000L-UM302B-EN-P – June 2013
7000 “C” Frame - Marine
Removable cover for
access to load cables
with UPS removed
Figure 2.54 – Access to Load Terminals (bottom covers and UPS removed)
Load cable terminals
with barrier plate
removed
Figure 2.55 – Access to Load Terminals (bottom covers, UPS and terminal barrier removed)
