2-44

Drive Installation

7000L-UM302B-EN-P – June 2013

7000 “C” Frame - Marine



Motor Filter

Capacitors

De-ionizer
Cartridge

Voltage

Sensing

Heat
Exchanger

Coolant
Pumps

Grounding

Network

Motor

Terminals

Figure 2.51 – Pump Cabinet (swing-out low voltage panel removed)
