The 80190-759-02 Universal Encoder Interface is functionally
identical to the 80190-759-01 with the addition of conformal coating.
The Universal Encoder interface is configured via jumpers installed
on the 12-position header J4. The header has three positions labeled
‗Park‘ and used to store the jumpers when indicated as ―Removed‖
in the table below. Each function is selected by moving its
corresponding jumper from the ‗park‘ location to the selected
function location if labeled ―Installed‖. The following table describes
the functions available.

A T T E N T I O N

A T T E N T I O N

Removing the Universal Encoder Interface
while control power is applied may result in
damage to the board. Only remove the board
when the control power is Off.


Table 4.F – Encoder Configurations

ENC_TYPE

POL_QRDNT

CD_DQUAD

CONFIGURATION

Installed

Installed

Installed

Single Quadrature Encoder Option (Factory Default)

Installed

Installed

Removed

Dual Quadrature Encoder Option without Redundancy

Installed

Removed

Removed

Dual Quadrature Encoder Option with Redundancy

Installed

Removed

Installed

Single Quadrature Option (CDSEL/DQUAD) must be
removed for Redundancy

Removed

Installed

Installed

Gray Code Absolute Encoder Low True

Removed

Installed

Removed

Natural Binary Absolute Encoder Low True

Removed

Removed

Installed

Gray Code Absolute Encoder High True

Removed

Removed

Removed

Natural Binary Absolute Encoder High True



Figure 4.75 – Universal Encoder Board

Tachometer Feedback Board

(cont.)
