M+ l+ l- m, M+ l – Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 44
2-14
Drive Installation
7000L-UM302B-EN-P – June 2013
7000 “C” Frame - Marine
Connect the Sections (cont.)
M+
L+
L-
M-
M10 Carriage Bolt
M10 Washer
M10 Lockwasher
M10 Nut
Figure 2.13 – Capacitor Cabinet
(Connect left side of Medium Voltage bus pieces with M10 hardware)
Connect cables from DC Link Choke to MV Bus pieces using
supplied M12 hardware.
M+
L+
L-
M-
Figure 2.14 – DC Link Choke Cabinet after connection of cables from DC Link Choke to red insulators
