Drive Installation 2-13

7000 “C” Frame - Marine

7000L-UM302B-EN-P – June 2013

M-

M+

L+

L-

Figure 2.11 – DC Link Choke Cabinet after field connections of power bus

M+

L+

L-

M-

Figure 2.12 – Capacitor Cabinet after field connections of power bus
