Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 56
2-26
Drive Installation
7000L-UM302B-EN-P – June 2013
7000 “C” Frame - Marine
Internally mounted fans
Capacitor cabinets have internally mounted fans which are installed
and wired by Rockwell Automation (refer to Figure 2.35). The
customer only needs to install the fan hood.
Fan Hood to be installed on site
Internally mounted fans
Figure 2.35 – Fan Hood Installation (Internally Mounted Fans)
