Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 178
4-2
Component Definition and Maintenance
7000L-UM302B-EN-P – June 2013
7000 ―C‖ Frame - Marine
Motor Terminals
Line Terminals
Hall-Effect Sensor
Voltage Sensing
Hall-Effect Sensor
Surge Arresters
Current Transformer
Current Transformer
Figure 4.2 – Large Footprint AFE Control and Cabling Cabinet
(with LV Control Panel removed)
