4-20

Component Definition and Maintenance

7000L-UM302B-EN-P – June 2013

7000 ―C‖ Frame - Marine

Testing Filter Capacitors

1. Ensure there is no power to the equipment before testing the

capacitor.

A T T E N T I O N

A T T E N T I O N

To prevent electrical shock ensure the main
power has been disconnected before working on
the capacitor. Verify that all circuits are voltage
free using a hot stick or appropriate voltage-
measuring device. Failure to do so may result in
injury or death..

A T T E N T I O N

A T T E N T I O N

Verify the load is not running due to process. A
freewheeling motor can generate voltage that
will be back-fed to the equipment being worked
on.

2. Follow appropriate safety steps to isolate the equipment from

medium voltage.


3. Verify that there is no voltage present on the capacitor by using a

hot stick or any other appropriate voltage-measuring device.


4. Perform visual inspection to ensure there is no oil leak or bulge

in any of the capacitors.

5. Note the location of all the cables and mark them accordingly.

6. Disconnect power cables from the capacitor terminals on all four

bushings and isolate them from the capacitor.

7. Connect a low voltage single-phase test power, for instance

110V or 220V, across a phase and the neutral of the capacitor.
Switch on the test power and measure the test voltage and
current drawn by the capacitor. Repeat the test for all three
phases and note down the test voltage and current.

A T T E N T I O N

A T T E N T I O N

The capacitor will charge during this test so care
must be taken to prevent a shock or injury.
When moving the test connections from one
phase to the next, wait for at least five minutes
until the capacitor is discharged. Using a hot
stick.

Filter Capacitor Cabinet

(cont.)
