Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 75
Drive Installation 2-45
7000 “C” Frame - Marine
7000L-UM302B-EN-P – June 2013
Removable cover for
access to load cables
UPS and Battery pack
Removable cover for
access to local cables
Figure 2.52 – Access to Load Terminals (components installed)
Voltage Sensing
Board (VSB)
Figure 2.53 – Access to Load Terminals (bottom covers removed)
