Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 40
2-10
Drive Installation
7000L-UM302B-EN-P – June 2013
7000 “C” Frame - Marine
Connect the Sections
(cont.)
Pipe Splice #1
Capacitor
Cabinet
DC Link
Choke Cabinet
Pipe Splice #2
Figure 2.5 – CPVC Pipe Splices (Capacitor #2 not shown for clarity)
Figure 2.6 – Typical Strap Wrench (not supplied)
used to tighten unions on CPVC pipe splices
