Drive Installation 2-39

7000 “C” Frame - Marine

7000L-UM302B-EN-P – June 2013



Voltage Sensing

Surge Suppression

Network

Hall Effect Sensor

Ground Bus

Line Terminals

Line Capacitors

Figure 2.46 – Line Reactor and Incoming Cabling Cabinet
