Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 189
Component Definition and Maintenance 4-13
7000 ―C‖ Frame - Marine
7000L-UM302B-EN-P – June 2013
Important:
Torque on capacitor terminals
3.4 Nm (30 lb-in)
Loosen screws to release capacitor
Figure 4.8 – Capacitor in Grounding Network
Capacitors
Reactor Transformer
Resistor Bank
Figure 4.9 – Location of Ground Filter in ‘C’ Frame Drive
