4-22

Component Definition and Maintenance

7000L-UM302B-EN-P – June 2013

7000 ―C‖ Frame - Marine

Converter Cabinet Components


Inverter Modules

Ground Bus

Isolated Gate Driver
Power Supplies

Coolant Piping

Rectifier Modules

Figure 4.15 – Converter Cabinet Components

(standard 4160V AFE design shown)
