Overview of Drive 1-11
7000 “C” Frame - Marine 7000L-UM302B-EN-P – June 2013
Description Specifications
Control Power 220/240 V or 110/120 V, 1 phase – 50/60 Hz (20 Amp)
External I/O 16 Digital Inputs, 16 Digital Outputs
External Input Ratings
50/60 Hz AC or DC
120-240 V – 1 mA
External Output Ratings
50-60 Hz AC or DC
30-260 V – 1 amp
Analog Inputs (3) Isolated, 4-20mA or 0-10 V
Analog Resolution
• Analog input 12 Bit (4-20 mA)
• Analog input 13 Bit (0-10V)
Analog Outputs
• (1) Isolated, 4-20 mA
• (8) Non-isolated, 0-10 V
Communication Interface DPI
Scan Time Internal DPI – 2 ms min., 4 ms max.
Communications Protocols
(Optional)
R I/O Lon Works
DeviceNet Can Open
Ethernet RS485 HVAC
Profibus RS485 DF1
Modbus RS232 DF1
Interbus USB
Enclosure NEMA 1 (IP21), NEMA 12 (IP42)
Lifting Device Standard / Removable
Mounting Arrangement Mounting Sill Channels
Structure Finish
Epoxy Powder – Paint
Exterior Sandtex Light Grey (RAL 7038) – Black (RAL 8022)
Internal – Control Sub Plates – High Gloss White (RAL 9003)
Interlocking Key provision for customer input Disconnecting Device
Corrosion Protection Unpainted Parts (Zinc Plates / Bronze Chromate)
Fiber Optic Interface Rectifier – Inverter – Cabinet (Warning/Trip)
Door Filter Painted Diffuser with Matted Filter Media
Door Filter Blockage Air Flow Restriction Trip/Warning
Coolant
Iron and chlorine free ethylene glycol
mixed with de-ionized water
Coolant Conductivity 1-2 micro-Siemens/CM
Heat Exchangers Liquid-to-Air, Liquid-to-Liquid
Ambient Temperature 0° to 45°C (32°F to 113°F)
Storage and Transportation
Temperature Range
-40°C to 70°C (-40°F to 185°F)
Relative Humidity 95% Non-Condensing
Altitude (Standard) 0 to 3300 ft. (0 to 1000 m)
Altitude (Optional) 0 to 16400 ft. (1001 to 5000 m)
Seismic (UBC Rating) 1, 2, 3, 4
Standards NEMA, IEC, CSA, UL, ANSI, IEEE
