Drive Installation 2-43

7000 “C” Frame - Marine

7000L-UM302B-EN-P – June 2013


Output

Contactor

Control

Module

Customer
Terminal

Blocks

Marine UPS

Customer
I/O Control
Board (XIO)

Drive
Control
Boards
(ACB)

Communication
Card


Figure 2.50 – Pump Cabinet (showing swing-out low voltage panel)
