Drive processor module (cont.) – Rockwell Automation 7000L PowerFlex 7000 Medium Voltage AC Drive C Frame - Marine User Manual
Page 268
4-92
Component Definition and Maintenance
7000L-UM302B-EN-P – June 2013
7000 ―C‖ Frame - Marine
11. Program the drive. Refer to Technical Data ―Medium Voltage
AC Drive Parameters‖ – Publication 7000-TD002_-EN-P. The
parameters should also be saved to NVRAM and then externally
to the drive using the options described earlier in this section.
Analog Control Board
(ACB)
ANALOG
CONTROL
BOARD
Figure 4.68 – ACB and DPM Replacement
Drive Processor Module
(cont.)
