4-62

Component Definition and Maintenance

7000L-UM302B-EN-P – June 2013

7000 ―C‖ Frame - Marine

Location

The AC/DC power supply is located in the low voltage panel
in the far right-hand section of the drive. A typical low voltage
compartment is shown in Figure 4.48.

AC/DC Power Supplies

(Pioneer)


Figure 4.48 – Location of AC/DC Pioneer Power Supply on Low Voltage Panel

AC/DC Power Supply

(cont.)
