2-22 Drive Installation
7000L-UM302B-EN-P – June 2013 7000 “C” Frame - Marine
Removal of DC Link Choke Turnbuckle Supports (if used on design supplied)
Remove turnbuckles which attach choke to top lifting angle pair as
follows:
 Remove cotter pins (see Fig. 2.32) from bottom turnbuckle jaw then
top. Carefully remove turnbuckles. Retain for future use.
Remove cotter pins
Figure 2.32 – Choke Cabinet
 Re-install any capacitors that were removed.
 Proceed with Removal of Lifting Angles.
