Publication 1756-UM009C-EN-P - December 2010 59
Non-isolated Analog Voltage/Current Input Modules (1756-IF16, 1756-IF8) Chapter 4
Features Specific to
Non-Isolated Analog
Input Modules The table lists features that are specific to the 1756-IF16 and
1756-IF8 modules.
Multiple Input Ranges
You can select from a series of operational ranges for each channel on your
module. The range designates the minimum and maximum signals that are
detectable by the module.
See page 210 for an example of how to choose an input range for your module.
Feature Page
Multiple Input Ranges 59
Module Filter 60
Real Time Sampling 61
Underrange/Overrange Detection 61
Digital Filter 62
Process Alarms 63
Rate Alarm 64
Wire Off Detection 64
Module Possible Ranges
1756-IF16 and 1756-IF8 -10…10V
0…5V
0…10V
0…20 mA
