Publication 1756-UM009C-EN-P - December 2010 149
Chapter
7
Non-isolated Analog Output Modules
(1756-OF4 and 1756-OF8)
Introduction This chapter describes features specific to ControlLogix non-isolated analog
output modules.
The non-isolated analog output modules also support features described in
Chapter 3 . See the table for some of these features.
Topic Page
Choose a Data Format 150
Non-isolated Output Module Features 150
Use Module Block and Output Circuit Diagrams 154
Wire the 1756-OF4 Module 157
Wire the 1756-OF8 Module 158
1756-OF4 and 1756-OF8 Module Fault and Status Reporting 159
Feature Page
Removal and Insertion Under Power (RIUP) 36
Module Fault Reporting 36
Configurable Software 36
Electronic Keying 37
Access to System Clock for Timestamp Functions 44
Rolling Timestamp 44
Producer/Consumer Model 44
Status Indicator Information 45
Full Class I Division 2 Compliance 45
Agency Certification 45
Field Calibration 45
Sensor Offset 46
Latching of Alarms 46
