Configuration process overview – Rockwell Automation 1756-XXXX ControlLogix Analog I/O Modules User Manual
Page 200
200
Publication 1756-UM009C-EN-P - December 2010
Chapter 10 Configure ControlLogix Analog I/O Modules
Configuration Process Overview
Follow these basic steps to configure a ControlLogix analog I/O module by
using the RSLogix 5000 software.
1.
Create a new module.
2.
Accept the default configuration or change it to specific configuration
(customized) for the module.
3.
Edit a configuration for a module when changes are needed.
Each of these steps is explained in detail in the following pages. A chart that
shows the full configuration profile is on
IMPORTANT
This section focuses on configuring I/O modules in a local
chassis. To configure I/O modules in a remote chassis, you must
follow all the detailed procedures with two additional steps.
See
for details.
RSLogix 5000 programming software must be installed on your
computer to complete the procedures for both default and
custom configurations.
For software installation instructions and to learn how to
navigate the software package, se
.
