350

Publication 1756-UM009C-EN-P - December 2010

Appendix C Use Ladder Logic To Perform Run Time Services and Reconfiguration

Communication Dialog Boxes

The examples show the Communication dialog boxes for different versions of
RSLogix 5000 software.

The top example is for rung 0 if using RSLogix 5000, version 9 and earlier. The
window is the same for each rung of this example.

RSLogix 5000 Software, Version 9 and Earlier

RSLogix 5000 Software, Version 10 and Later

IMPORTANT

You must name an I/O module to set the message path under
that module’s communication tab.
