106

Publication 1756-UM009C-EN-P - December 2010

Chapter 5 Sourcing Current Loop Input Module (1756-IF6CIS) and Isolated Analog Voltage/Current Input Module (1756-IF6I)

Wire the
1756-IF6CIS Module

1756-IF6CIS – Two -wire transmitter connected to the module

and the module providing 24V DC loop power

+

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

VOUT-1

IN-1/I

RTN-1

VOUT-3

IN-3/I

RTN-3

Not used

VOUT-5

IN-5/I

RTN-5

VOUT-0

IN-0/I

RTN-0

VOUT-2

IN-2/I

RTN-2

Not used

VOUT-4

IN-4/I

RTN-4

2-Wire
Transmitter

43469

Shield Ground

NOTES:

1. Do not connect more than two wires to any single terminal.

2. Place additional loop devices (that is, strip chart recorders) at

either ’A’ location in the current loop.

A

i

A
