Publication 1756-UM009C-EN-P - December 2010 139
Temperature-measuring Analog Modules (1756-IR6I, 1756-IT6I, and 1756-IT6I2) Chapter 6
1756-IT6I Wiring Example
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
+
–
Lug
Wire
20969-M
IN-0
Not used
RTN-0
IN-2
Not used
RTN-2
Not used
IN-4
Not used
RTN-4
IN-1
Not used
RTN-1
IN-3
CJC+
RTN-3
CJC-
IN-5
Not used
RTN-5
Thermocouple
Cold
Junction
Sensor
Lug
Wire
Thermocouple
NOTES:
1. Do not connect more than two wires to
any single terminal.
