Publication 1756-UM009C-EN-P - December 2010

231

Configure ControlLogix Analog I/O Modules Chapter 10

For more information on the ControlLogix ControlNet module, see
ControlNet Modules in Logix5000 Control Systems,
publication

CNET-UM001

.

For more information on the ControlLogix EtherNet/IP Bridge
module, see EtherNet/IP Modules in Logix5000 Control Systems User
Manual, publication

ENET-UM001

.

6.

Repeat steps

1

5

to configure a communication module for the

remote chassis.

7.

Configure the communication module in the remote chassis.

Now you can configure the remote I/O modules by adding them to the
remote communication module. Follow the same procedures as you do
for configuring local I/O modules, starting on

page 202

.

8.

Click Reset for the appropriate point setting in the Reset Latched
Diagnostics column.

9.

Click OK.
