316

Publication 1756-UM009C-EN-P - December 2010

Appendix A Analog I/O Module Specifications

1756-OF6CI

ControlLogix current loop output analog module

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

i

OUT-1

ALT-1

RTN-1

OUT-3

RTN-3

Not Used

OUT-5

ALT-5

ALT-3

RTN-5

OUT-0

ALT-0

RTN-0

OUT-2

RTN-2

Not Used

OUT-4

ALT-4

ALT-2

RTN-4

User Analog
Output Device

Shield
Ground

1756-OF6CI 0...550

Ω

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

i

OUT-1

ALT-1

RTN-1

OUT-3

RTN-3

Not Used

OUT-5

ALT-5

ALT-3

RTN-5

OUT-0

ALT-0

RTN-0

OUT-2

RTN-2

Not Used

OUT-4

ALT-4

ALT-2

RTN-4

User Analog
Output Device

Shield Ground

1756-OF6CI 551...1000

Ω

· Place additional devices anywhere in the loop.
· Do not connect more than two wires to any single terminal.

· Place additional devices anywhere in the loop.
· Do not connect more than two wires to any single terminal.

Input Signal to User Count Conversion - 1756-OF6CI

Range

Low Signal and User Counts

High Signal and User Counts

0...20 mA

0 mA

-32768 counts

21.074 mA

32767 counts

Technical Specifications - 1756-OF6CI

Attribute

1756-OF6CI

Outputs

6 individually isolated

Output range

0…21 mA

Resolution

13 bits across 21 mA (2.7

μ

A)

Current draw @ 5.1V

250 mA for 0...550 W loads terminated on OUTs and RTNs
(Total backplane power in this range 6.7 W)
250 mA for 551...1000 W loads terminated on OUTs and ALTs
(Total backplane power in this range 8.5 W)

ANALOG OUTPUT

CAL

OK
