Appendix A Analog I/O Module Specifications
Thermal dissipation
Voltage: 7.84 BTU/hr
Current: 13.3 BTU/hr
Input impedance
Voltage: >10 M
Ω
Current: 249
Ω
Open circuit detection time
Differential voltage - Positive full scale reading within 5 s
Single-ended/differential current - Negative full scale
reading within 5 s
Single-ended voltage - Even numbered channels go to
positive full scale reading within 5 s, odd numbered
channels go to negative full scale reading within 5 s
Overvoltage protection, max
Voltage: 30V DC
Current: 8V DC
Normal mode noise rejection
>80 dB @ 60 Hz
(1)
Common mode noise rejection
100 dB @ 50/60 Hz
Channel bandwidth
15 Hz (-3 dB)
(1)
Settling time
<80 ms to 5% of full scale
(1)
Calibrated accuracy 25 °C (77 °F)
Voltage: Better than 0.05% of range
Current: Better than 0.15% of range
Offset drift
45
μ
V/°C
Gain drift with temperature
Voltage: 15 ppm
Current: 20 ppm
Module error
Voltage: 0.1% of range
Current: 0.3% of range
Module input scan time, min
16 pt single-ended: 16…488 ms
8 pt differential: 8…244 ms
4 pt differential: 5…122 ms
Isolation voltage
250V (continuous), reinforced insulation type,
inputs-to-backplane
No isolation between individual inputs
Routine tested at 1350V AC for 2 s
Removable terminal block
1756-TBCH
1756-TBS6H
Slot width
1
Wire size
0.33…2.1 mm
2
(22…14 AWG) solid or stranded copper
wire rated at 90 °C (194 °F), or greater, 1.2 mm
(0.047 in.) insulation max
(2)
Wire category
2
(3)
North American temperature code
T4A
IEC temperature code
T4
Enclosure type
None (open-style)
(1)
Notch filter dependent.
(2)
Maximum wire size requires extended housing, catalog number 1756-TBE.
(3)
Use this conductor category information for planning conductor routing as described in the system-level
installation manual. See the Industrial Automation Wiring and Grounding Guidelines, publication
Technical Specifications - 1756-IF16
Attribute
1756-IF16
