Rockwell Automation 1756-XXXX ControlLogix Analog I/O Modules User Manual
Page 385

Publication 1756-UM009C-EN-P - December 2010
385
1492 AIFMs for Analog I/O Modules Appendix F
1756-IF16
Single-ended
current
1492-AIFM8-3
Feed-through
8- or 16-channel
input or output
with 3
terminals/channel
1492-ACABLExUB
1492-AIFM16-F-3
N/A
Fusible
16-channel input
with 24V DC blown
fuse indicators, 3
terminals/channel
1492-AIFM16-F-5
16-channel input
with 24V DC blown
fuse indicators, 5
terminals/channel
Single-ended
voltage
1492-AIFM8-3
Feed-through
8- or 16-channel
input or output
with 3
terminals/channel
1492-ACABLExUA
1492-AIFM16-F-3
N/A
Fusible
16-channel input
with 24V DC blown
fuse indicators, 3
terminals/channel
1492-AIFM16-F-5
16-channel input
with 24V DC blown
fuse indicators, 5
terminals/channel
Differential
current
1492-AIFM8-3
Feed-through
8- or 16-channel
input or output
with 3
terminals/channel
1492-ACABLExUD
1492-AIFM8-F-5
N/A
Fusible
8-channel input
with 24V DC blown
fuse indicators, 5
terminals/channel
1492-AIFM16-F-3
16-channel input
with 24V DC blown
fuse indicators, 3
terminals/channel
1492-AIFM16-F-5
16-channel input
with 24V DC blown
fuse indicators, 5
terminals/channel
I/O Cat. No.
(1)
Mode
AIFM Cat. No.
(Fixed Terminal
Block)
AIFM Cat. No.
(RTB Socket
Assembly)
AIFM Type
Description
Pre-wired Cable
(5)
(x=cable length)
