52 Publication 1756-UM009C-EN-P - December 2010
Chapter 3 ControlLogix Analog I/O Module Features
In integer mode, input modules generate digital signal values that correspond
to a range from -32,768…32,767 counts.
The table lists the conversions of a generated digital signal to the number
of counts.
Output modules let you generate an analog signal at the screw terminals that
correspond to a range from -32,768…32,767 counts.
Input Signal to User Count Conversion
Input Module Available
Range Low Signal and
User Counts High Signal and
User Counts
1756-IF16/IF8 +/- 10V -10.25V
-32768 counts
10.25V
32767 counts
0…10V 0V
-32768 counts
10.25V
32767 counts
0…5V 0V
-32768 counts
5.125V
32767 counts
0…20 mA 0 mA
-32768 counts
20.58 mA
32767 counts
1756-IF6CIS 0…20 mA 0 mA
-32768 counts
21.09376 mA
32767 counts
1756-IF6I +/- 10V -10.54688V
-32768 counts
10.54688V
32767 counts
0…10V 0V
-32768 counts
10.54688V
32767 counts
0…5V 0V
-32768 counts
5.27344V
32767 counts
0…20 mA 0 mA
-32768 counts
21.09376 mA
32767 counts
1756-IR6I 1…487
Ω
0.859068653
Ω
-32768 counts
507.862
Ω
32767 counts
2…1000
Ω
2
Ω
-32768 counts
1016.502
Ω
32767 counts
4…2000
Ω
4
Ω
-32768 counts
2033.780
Ω
32767 counts
8…4020
Ω
8
Ω
-32768 counts
4068.392
Ω
32767 counts
1756-IT6I and
1756-IT6I2 -12…30mV -15.80323 mV
-32768 counts
31.396 mV
32767 counts
-12…78mV -15.15836 mV
-32768 counts
79.241 mV
32767 counts
