Publication 1756-UM009C-EN-P - December 2010 387
1492 AIFMs for Analog I/O Modules Appendix F
The table describes the I/O module-ready pre-wired cables available for use
with your ControlLogix analog I/O modules.
Cat. No.
(1)
No. of Conductors
(2) (3) Conductor Size Nominal Outer
Diameter RTB at the I/O
Module End
1492-ACABLExM 11 twisted pairs 22 AWG 11.5 mm (0.45 in.) 1756-TBCH
1492-ACABLExX 9 twisted pairs 22 AWG 6.8 mm (0.27 in.) 1756-TBNH
1492-ACABLExY 9 twisted pairs 22 AWG 6.8 mm (0.27 in.) 1756-TBNH
1492-ACABLExYT 9 twisted pairs 22 AWG 6.8 mm (0.27 in.) 1756-TBNH
1492-ACABLExZ 20 conductors 22 AWG 8.4 mm (0.33 in.) 1756-TBNH
1492-ACABLExTA 20 conductors 22 AWG 8.4 mm (0.33 in.) 1756-TBCH
1492-ACABLExTB 20 conductors 22 AWG 8.4 mm (0.33 in.) 1756-TBCH
1492-ACABLExTC 5 twisted pairs 22 AWG 8.4 mm (0.33 in.) 1756-TBCH
1492-ACABLExTD 5 twisted pairs 22 AWG 8.4 mm (0.33 in.) 1756-TBCH
1492-ACABLExUA 20 conductors 22 AWG 8.4 mm (0.33 in.) 1756-TBCH
1492-ACABLExUB 20 conductors 22 AWG 8.4 mm (0.33 in.) 1756-TBCH
1492-ACABLExUC 9 twisted pairs 22 AWG 6.8 mm (0.27 in.) 1756-TBCH
1492-ACABLExUD 9 twisted pairs 22 AWG 6.8 mm (0.27 in.) 1756-TBCH
1492-ACABLExVA 20 conductors 22 AWG 8.4 mm (0.33 in.) 1756-TBNH
1492-ACABLExVB 20 conductors 22 AWG 8.4 mm (0.33 in.) 1756-TBNH
1492-ACABLExWA 9 twisted pairs 22 AWG 6.8 mm (0.27 in.) 1756-TBNH
1492-ACABLExWB 9 twisted pairs 22 AWG 6.8 mm (0.27 in.) 1756-TBNH
(1) Cables are available in lengths of 0.5m, 1.0m, 2.5m, and 5.0m. To order, insert the code for the desired cable length into the catalog number in place of the x: 005=0.5m,
010=1.0m, 25=2.5m, 050=5m. Build-to-order cable lengths are also available.
(2) Each cable for analog I/O has an overall shield with a ring lug on a 200mm (8.87 in.) exposed drain wire at the I/O module end of the cable.
(3)
Not every connection is always used.
