Chapter

6

Temperature-measuring Analog Modules
(1756-IR6I, 1756-IT6I, and 1756-IT6I2)

Introduction

This chapter describes features specific to temperature-measuring
ControlLogix analog modules. These units linearize their respective sensor
inputs into a temperature value. The 1756-IR6I uses ohms for temperature
conversions and the two thermocouple modules (1756-IT6I, 1756-IT6I2)
convert millivolts.

These modules also support features described in

Chapter 3

. See the table for

some of these features.

Topic

Page

Choose a Data Format

120

Temperature-measuring Module Features

121

Differences Between the 1756-IT6I and 1756-IT6I2 Modules

131

Use Module Block and Input Circuit Diagrams

136

Wire the Modules

138

1756-IT6I Wiring Example

139

1756-IT6I2 Wiring Example

140

Fault and Status Reporting

141

Fault Reporting in Floating Point Mode

142

Fault Reporting in Integer Mode

145

Feature

Page

Removal and Insertion Under Power (RIUP)

36

Module Fault Reporting

36

Configurable Software

36

Electronic Keying

37

Access to System Clock for Timestamp Functions

44

Rolling Timestamp

44

Producer/Consumer Model

44

Status Indicator Information

45

Full Class I Division 2 Compliance

45

Agency Certification

45

Field Calibration

45

Sensor Offset

46

Latching of Alarms

46
