330

Publication 1756-UM009C-EN-P - December 2010

Appendix B Analog I/O Tag Definitions

Ch0HoldForInit

BOOL

All outputs

When set configures the channel to hold, or not change, until initialized with a
value within 0.1% of full scale of its current value when one of the following
conditions occurs.

1 = Module initial connection (power up).
2 = Module transition from Program mode back to Run mode.
3 = Module reestablishes communication after a fault.

Ch0Fault Mode

BOOL

All outputs

Selects the behavior the output channel should take if a communication fault
occurs. Either hold last state (0) or go to a user-defined
value (1). Ch0FaultValue defines the value to go to on fault if the bit is set.

Ch0ProgMode

BOOL

All outputs

Selects the behavior the output channel when transitioned into Program
mode. Either hold last state (0) or go to a user-defined value (1). Ch0ProgValue
defines the value to go to on fault if the bit is set.

Ch0RampToProg

BOOL

All outputs

Enables ramping of the output value to a use-defined Program value,
Ch0ProgValue, when set. Ramping defines the maximum rate the output is
allowed to transition based upon the configured Ch0RampRate.

Ch0RampToFault

BOOL

All outputs

Enables ramping of the output value to a user-defined Fault value,
Ch0FaultValue, when set. Ramping defines the maximum rate the output is
allowed to transition based upon the configured Ch0RampRate.

Ch0FaultValue

INT

All outputs

Defines the value, in counts, the output should take if a communication fault
occurs when the Ch0FaultMode bit is set.

Ch0ProgValue

INT

All outputs

Defines the value, in counts, the output should take when the connection
transitions to Program mode if the Ch0ProgMode bit is set.

Ch0RampRate

INT

All outputs

Configures the maximum rate that the output value may change when
transitioning to either the Ch0FaultValue or Ch0ProgValue if either the
Ch0RampToFault or Ch0RampToProg bits are set, respectively. In terms of
percent full-scale per second.

Integer Configuration Tags

Tag Name

Data Type

Applicable
Modules

Definition
