206

Publication 1756-UM009C-EN-P - December 2010

Chapter 10 Configure ControlLogix Analog I/O Modules

Floating point input data when the 1756-IF16 or 1756-IF8 module is operating in the
differential mode only

Float data - differential mode

Returns floating point input data when the 1756-IF16 or 1756-IF8 module is operating in the
high-speed mode

Float data - high-speed mode

Floating point input data when the 1756-IF16 or 1756-IF8 module is operating in the
single-ended mode

Float data - single-ended mode

Integer input data when the 1756-IF16 or 1756-IF8 module is operating in the differential mode

Integer data - differential mode

Integer input data when the 1756-IF16 or 1756-IF8 module is operating in the high-speed mode

Integer data - high-speed mode

Integer input data when the 1756-IF16 or 1756-IF8 module is operating in the single-ended mode

Integer data - single-ended
mode

Specific input data that is used by a controller that does not own the input module

These choices have the same definition as the similarly-named options above except that they
represent listen-only connections between the analog input module and a listen-only controller

Listen only CST timestamped
float data

Listen only CST timestamped
integer data

Listen only float data

Listen only integer data

Listen only CST timestamped
float data - differential mode

Listen only CST timestamped
float data - high-speed mode

Listen only CST timestamped
float data - single-ended mode

Listen only CST timestamped
integer data - differential mode

Listen only CST timestamped
integer data - high-speed mode

Listen only CST timestamped
integer data - single-ended
mode

Listen only Float data -
differential mode

Listen only Float data -
high-speed mode

Listen only Float data -
single-ended mode

Listen only Integer data -
differential mode

Listen only Integer data -
high-speed mode

Listen only Integer data -
single-ended mode

Input Module Communication Formats

If you want the input module to return this data

Choose this
communication format
