Rockwell Automation 1756-XXXX ControlLogix Analog I/O Modules User Manual
Page 193
Publication 1756-UM009C-EN-P - December 2010
193
Install ControlLogix I/O Modules Chapter 9
Spring clamp
- catalog number 1756-TBS6H
1.
Insert the screwdriver into the outer hole of the RTB.
2.
Insert the wire into the open terminal and remove the screwdriver.
ATTENTION
The ControlLogix system has been agency certified using only
the ControlLogix RTBs (catalog numbers 1756-TBCH,
1756-TBNH, 1756-TBSH and 1756-TBS6H). Any application that
requires agency certification of the ControlLogix system using
other wiring termination methods may require application
specific approval by the certifying agency.
20860-M
