Publication 1756-UM009C-EN-P - December 2010

177

Isolated Analog Output Modules (1756-OF6CI and 1756-OF6VI) Chapter 8

Wire the
1756-OF6CI Module

The illustration shows wiring examples for the 1756-OF6CI module.

1756-OF6CI Wiring Example for Loads of 0-550

Ω

1756-OF6CI Wiring Example for Loads of 551-1000

Ω

OUT-0

ALT-0

RTN-0

OUT-2

ALT-2

RTN-2

Not used

OUT-4

ALT-4

RTN-4

OUT-1

ALT-1

RTN-1

OUT-3

ALT-3

RTN-3

Not used

OUT-5

ALT-5

RTN-5

Shield Ground

User Analog

Output Device

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

i

NOTES:

1. Place additional devices

anywhere in the loop.

2. Do not connect more than two

wires to any single terminal.

User Analog
Output Device

i

Shield Ground

20967-M

Shield Ground

User Analog

Output Device

OUT-0

ALT-0

RTN-0

OUT-2

ALT-2

RTN-2

Not used

OUT-4

ALT-4

RTN-4

OUT-1

ALT-1

RTN-1

OUT-3

ALT-3

RTN-3

Not used

OUT-5

ALT-5

RTN-5

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

i

NOTES:

1. Place additional devices

anywhere in the loop.

2. Do not connect more than two

wires to any single terminal.

User Analog
Output Device

i

Shield Ground
