p STC-2002 DEPOSITION CONTROLLER y
SECTION 6.XX e page 211 of 276 ^
Value Range UNUS ED (DISABLED) / INPUT / OUTPUT
Units None
______________________________________________________________________
Parameter 30
I/O Slot 3 Type
access value: REQIO3 Require Input/Output 3 in system, CFGIOS_class
Value Range UNUS ED (DISABLED) / INPUT / OUTPUT
Units None
______________________________________________________________________
Parameter 31
I/O Slot 4 Type
access value: REQIO4 Require Input/Output 4 in system, CFGIOS_class
Value Range UNUS ED (DISABLED) / INPUT / OUTPUT
Units None
______________________________________________________________________
Parameter 32
Memory Module IFC
access value: REQMEMMOD Require memory module option installation. Not auto detectable Boolean 1/0 True/False.
Value Range OFF/ON
Units None
______________________________________________________________________
______________________________________________________________________
Read, Write System Parameters Command Examples
Command
C10 or C 10
Response A15:33
Description
Read system parameter # 10, system clock time. Result is 15:33 hrs:mins, 3:33 p.m. time.
Command C18
Response A5
Description
Read system parameter # 18, NA.
Command
D11 = 70689
Response A
Description
Set system parameter 11, calendar date to July 6, 1989. Command received and accepted.
Command D
14= 1
Response A (Possible missed due baud change)
Description Set baud rate 1200 baud.
Table 6.10: Group 3 Examples.
______________________________________________________________________
______________________________________________________________________
Read RunTime Data Group 4 --
Command E
(E) Read RunTime Data. These commands are used for reading back real time numerical information
from STC-2002. This includes information such as rate, thickness, power, etc. The group
command is the letter E followed by a parameter number.
Read RunTime Data
