118 K2 Storage System Instruction Manual June 25, 2009
Chapter 3 Installing the Level 10R Storage System
g. Close the Progress Report and repeat these steps for other unbound disks. If
specified by your system design, you can bind some disks as Hot Spares, as
explained in
“Binding Hot Spare drives” on page 551 . When you are done, if
you did not bind any extra Hot Spares, you should have the following results:
For L10R storage, on the primary RAID chassis you should have two RAID 1
RANKs of two disks each, one Hot Spare Disk, and one RAID 5 or RAID 6
RANK of six disks. For each optional Expansion chassis, you would have an
additional one or two RAID 5 or RAID 6 RANKs of six disks each.
h. Click Close in Progress Report window.
4. Restart the K2 Media Server.
NOTE: Make sure start up processes on the K2 Media Server are complete before
proceeding.
5. Continue with the next procedure “Creating a new file system” .
Creating a new file system
1. In Storage Utility, click Tools | Make New File System . The Setting dialog box
opens.
