Checking power – Rockwell Automation 1783-WAPxxx Stratix 5100 Wireless Access Point User Manual User Manual
Page 49

Rockwell Automation Publication 1783-UM006A-EN-P - May 2014
49
Install the Stratix 5100 Wireless Access Point/Workgroup Bridge
Chapter 2
Checking Power
You can verify the availability of power to the access point/bridge by checking the
power injector
• Power status indicator
– Green color indicates input power is being supplied to the bridge.
– Red color indicates an overcurrent or overvoltage error condition—
disconnect input power from the power injector, check all coax cable
connections for a possible short, wait approximately 1 minute, and
reconnect input power to the power injector. If the status indicator
turns red again, contact technical support for assistance.
Off indicates input power is not available—verify that the power module is
connected to the power injector and that AC power is available.
Operating status
Blinking blue
Software upgrade in progress
Cycling through green, red, and
off
Discovery/join process in progress
Rapidly cycling through blue,
green, and red
Access point location command invoked
Blinking red
Ethernet link not operational
Boot loader warnings
Blinking blue
Configuration recovery in progress (MODE button pushed
for 2…3 seconds)
Red
Ethernet failure or image recovery.
(MODE button pushed for 20…30 seconds)
Blinking green
Image recovery in progress (MODE button released)
Boot loader errors
Red
DRAM memory test failure
Blinking red and blue
Nonvolatile memory file system failure
Blinking red and off
Environment variable failure
Bad MAC address
Ethernet failure during image recovery
Start environment failure
No Cisco image file
Start failure
Cisco IOS errors
Red
Software failure; try disconnecting and reconnecting unit
power
Cycling through blue, green,
red, and off
General warning; insufficient in-line power
TIP
The power injector requires approximately 50 seconds to recover from
an overcurrent or overvoltage condition.
Table 4 - Status Indicator Descriptions (Continued)
Message Type
Status Indicator
Description
