Rockwell Automation Publication 1783-UM006A-EN-P - May 2014 193
Configure the Stratix 5100 WAP Using the Command-Line Interface Chapter 5
speed auto
bridge-group 1
no bridge-group 1 source-learning
bridge-group 1 spanning-disabled
!
interface FastEthernet0.40
encapsulation dot1Q 40
no ip route-cache
bridge-group 40
no bridge-group 40 source-learning
bridge-group 40 spanning-disabled
For the instructions in Device Manager, see Configuring Security on page 64
Assign an IP Address by Using
CLI When you connect the wireless device to the wired LAN, the wireless device links
to the network by using a bridge virtual interface (BVI) that it creates
automatically. Instead of tracking separate IP addresses for the wireless device
Ethernet and radio ports, the network uses the BVI.
When you assign an IP address to the wireless device by using CLI, you must
assign the address to the BVI. Beginning in privileged EXEC mode, follow these
steps to assign an IP address to the wireless device BVI:
1. Enter the global configuration mode to configure the terminal.
configure terminal
2. Enter interface configuration mode for the BVI.
interface bvil
3. Assign an IP address and address mask to the BVI.
ip address address mask
For the instructions in Device Manager, see Obtain and Assign an IP Address on
page 54
TIP If you are connected to the wireless device by using a Telnet session,
you lose your connection to the wireless device when you assign a new
IP address to the BVI. If you need to continue configuring the wireless
device by using Telnet, use the new IP address to open another Telnet
session to the wireless device.
