Install the Stratix 5100 Wireless Access Point/Workgroup Bridge
Chapter 2
Install the WAP
Install the Stratix 5100 WAP on a flat surface.
1. Unpack and remove the access point and the accessory kit from the
shipping box.
2. Return any packing material to the shipping container and save it for
future use.
3. Verify that you have received the items listed below.
• Access point
• Mounting bracket
• Power adapter, Cisco AIR-PWR-B
• Console cable
• Antennas, see
See If any item is missing or damaged, contact your Rockwell Automation,
see
on the back cover of this manual.
Other items you need to install the unit:
• ESD-preventive cord and wrist strap
• Ethernet cable
• Power supply
• Mounting screws
• Grounding wire
IDF Closets (telecommunications or other electrical equipment)
When installing WAPs near other electrical or telecommunications equipment,
keep all wiring and metal away from the antennas, and avoid placing the antennas
near electrical lines. Do not route electrical wiring or Ethernet in the near field 38
cm (15 in.) of the antenna, and try not to install the WAP in an electrical closet.
Local fire and safety regulations can require you to use a plenum-rated cable if
your remote antenna cables from an electrical closet. Remember that the best
place for the WAP is as close to its users.
For more information on interference, see these publications:
•
