Chapter 4 Stratix 5100 Device Manager Parameter Definitions
Match Classifications All switches and routers that access the Internet rely on the class information to
provide the same forwarding treatment to packets with the same class
information and different treatment to packets with different class information.
IP Precedence Eight IP precedence values are defined in RFC791. Select any of them as matching
criteria.
IP DSCP IP DSCP (Differentiated Service Code Point) is defined in RFC2474. Select IP DSCP
values as matching criteria.
IP Protocol 119 This protocol is for matching the SpectraLink Voice Protocol.
Apply Class of Services Determine the class of service that the access point applies to packets that match
the filter that you selected from the Filter menu. Click Add beside the Class of
Service pull-down.
Filter If you have filters set up, you can assign a priority to packets that match the
selected filter.
From the Filter pull-down menu, select the filter you want to include in the policy.
For example, you could assign a high priority to a MAC address filter that includes
the MAC addresses of IP phones.
The Define Filters link take you to Services>Filters where you can configure filters.
Note: The access list you use in QoS does not affect the access point's packet
forwarding decisions.
Rate Limiting Bits per Sec: 8000…2000000000
Burst Rate (Bytes): 1000…512000000
Confirm Action: Transmit
Exceed Action: Drop
Apply Policies to Interface/VLANs After QoS policies are created and applied, you can assign the policies to in-going
or out-going traffic of any of the two interfaces.
Incoming Use the pull-down menu to choose the policy you want to assign for
GigabitEthernet and 802.11 radio interfaces.
Outgoing Use the pull-down menu to choose the policy you want to assign for
GigabitEthernet and 802.11 radio interfaces.
Table 53 - QoS Policies Page Parameter Descriptions (Continued)
Parameter Description
