464 Rockwell Automation Publication 1783-UM006A-EN-P - May 2014
Chapter 16 Configuring QoS
13. Use the Apply Policies to Interface/VLANs pull-down menus to apply
policies to the access point Ethernet and radio ports.
• If VLANs are configured on the access point, pull-down menus for each
VLAN’s virtual ports appear in this section.
• If VLANs are not configured on the access point, pull-down menus for
each interface appear.
14. Click Apply at the bottom of the page to apply the policies to the access
point ports.
If you want the access point to give priority to all voice packets regardless
of VLAN, click the Advanced tab.
You can use the Cisco IOS command dot11 phone dot11e to enable the
future upgrade of the 7920 Wireless Phone firmware to support the standard
QBSS Load IE.
This example shows how to enable IEEE 802.11 phone support with the legacy
QBSS Load element:
AP(config)# dot11 phone
This example shows how to enable IEEE 802.11 phone support with the
standard (IEEE 802.11e draft 13) QBSS Load element:
AP(config)# dot11 phone dot11e
This example shows how to stop or disable the IEEE 802.11 phone support:
AP(config)# no dot11 phone
15. Policies you create on the access point—QoS Policies that you create and
apply to VLANs or to the access point interfaces are third in precedence
after previously classified packets and the QoS Element for Wireless
Phones setting.
16. Default classification for all packets on VLAN—If you set a default
classification for all packets on a VLAN, that policy is fourth in the
precedence list.
IMPORTANT This release continues to support existing 7920 wireless phone firmware. Don’t
attempt to use the new standard (IEEE 802.11e draft 13) QBSS Load IE with the
7920 Wireless Phone until new phone firmware is available for you to upgrade
your phones.
